Morgan City Pump Station

Location
Morgan City, La
Owner
Consolidated Gravity Drainage District of St. Mary Parish
Engineer
T. Baker Smith
General Contractor
Sealevel Construction
Status
Completed in 2023








.webp)

.webp)
.webp)

No items found.
Project Overview
Sealevel Construction led the Morgan City Pump Station project as the general contractor. The project consisted of:
- driving sheet piles of various lengths
- driving (73) 14 square inch foundation concrete piles 83’ in length in the sump
- pouring a seal slab and sump slab which consisted of 360 cubic yards of concrete
- forming and pouring all concrete shear walls and upper deck with the use of EFCO forms, which was collectively 812 cubic yards of concrete
- driving (12) 60’ timber piles along the bank and (64) 14 square inch concrete piles of various lengths
- forming and pouring of the discharge flume area which consisted of 4” (1,799 SY) & 6” (675 SY) slope paving
- construction of pump station metal building
- electrical scope performed by Sealevel-affiliated company, Rodrigue's Electrical Service
- fabrication and installation of discharge pipe
- disassembling the pumps and engines from the existing pump station and relocated them to the new pump station
- subcontracted Sealevel-affiliated company, Mike Evans Crane and Equipmetn Services for mechanical maintenance of engines
- dirt work, rip rap and limestone work on site at various stages of the project
